DISTRIBUTION UNIT
The Distribution Unit is connected to the main control panel with a purpose of supplying the system with power. It is robust, waterproof, oil resistant, ignition protected for mounting in an engine room and it can accommodate up to six Series S interceptors. The power cable is included for easy connection to a battery. The distribution unit has built-in electrical protection, including its own protection fuse.
SPECIFICATIONS
Model DU-S
Supply Voltage 12 - 32 V DC
Power Consumption 0.1 W max
Protection Fuse 10 A ATO
Power Cable Length 4 m (13 ft), Diameter 9 mm (0.35 in), 12 AWG
Operating Temperature -20° to +85°C (-4° to +185°F)
Storage Temperature -40° to +90°C (-40° to +194°F)
Waterproof Rating IP67 with cables and/or protective caps mounted
Oil resistance Common engine fluids
Compliance CE, FCC, SAEJ1171 Ignition Protected
Weight 1.0 kg (2.2 lbs) including the power cable
