Universal Low Voltage LED Dimmer

DMS-500 Universal Low Voltage LED Dimmer, 5A

$100.62
SKU:
ILDMS-500-X
Weight:
0.50 LBS
Shipping:
Calculated at Checkout
Adding to cart… The item has been added

DMS-500 Universal Low Voltage LED Dimmer, 5A

6-30VDC or 0-10V Control Input

With flicker-free, full range dimming performance, the DMS Series Universal Low Voltage LED Dimmer can dim most 12V-24V LED bulbs, flexible or rigid LED strips, and halogen/incandescent bulbs. We have found it also works very well with many types of LED-engineered fixtures, including our Sigma Series 2-wire LED fixtures.

  • Small compact form factor
  • High frequency PWM delivers flicker-free lighting at all levels
  • Smoothly dims typically hard to dim LED bulbs and flexible or rigid strips
  • Safety features include Overheat, No-Load, Overload, & Short Circuit protection
  • Can be controlled with a variety of input devices including momentary switches
  • Accepts 0-10V (source) input signal from 3rd party centralized control systems
  • Simple synchronization of multiple units for controlling larger loads
  • Minimum brightness adjustable with built-in potentiometer
  • Safe & reliable screw terminals
Housing Finish/Material White/Plastic
Dimensions 3.75" (96mm) l x 1.50" (40mm) w x 0.75" (20mm) h
Input Voltage 6-30VDC (or stable 0-10V source)
Stand by current <1.0mA
Load Rating 5A
Max Operating Temperature 0° C - +50° C
Dimmer Compatibility Most LED bulbs, LED strips, LED courtesy lights, Sigma, more
Dimmer Control Interface Single or double momentary push-button, potentiometer
Dimming Range 0-100% with most products
Mounting Method Two screws, double-side tape, or wire ties
Install Location Dry
Ingress Protection IP20
Electrical Protections Overheat, no-load, overload, short-circuit
Certifications & Compliance CE, ROHS
Warranty 5 Years

Click here for dimensional drawing





5 year manufacturer's warranty
!
